Organosheet Battery Casing
Last update: 02 Sep. 2024What is an organosheet Battery Casing?
PHEV Battery in thermoplastic composite for ligtweighting and reinforced mechanical and thermal battery protection.
0/0
What are our Battery casing benefits?
- Lightest solution on the market: up to 20% lighter than steel baseline
- 100% recyclable material
- Low Carbon Footprint
(1.4 to 3.1 CO2eq./kg) - Optimum thermal insulation
- Easy function integration thanks to plastic overmolding
Valeo Battery casing specifications
- Glass-fiber resin pre-impregnated thermoplastic composite
- Crash compliant
- Corrosion resistant
- Thermal insulation:
0.4-0.6 W/m.K - Fire resistant (UL94 V0):
>5 min@> 1000°C - One Shot/ NetShape” Process
- Valid for mass production
(300 K units/year) - Lightweight & strong
(400-500M Pa)
-
300,000
units/year
-
40%
Up to 40% lighter than metal solutions
-
100%
recyclable material
Vehicle type
- Passenger car
- Bus
- Truck
- Robot taxi
- Motorcycle
- Bike
- Droid
- Off road
